Embed printer T4

Products

Tel：+86-592-6518896

Fax ：+86-592-6518896

Mobile：+86-139-501-88408

Feature：

★ Smart appearance

★ Easy paper loading

★ Low noise thermal printing

★ Different interfaces optional

★ Easily embedded to any kinds of instruments and meters

Application:

◆ Medical Equipment

◆ Measureing Equipment

◆ Security Equipment

◆ Hospitality and Retail

◆ EFTs POS

Printing Method	Thermal Line
Communication interface	USB+RS232/TTL
Instruction set	ESC/POS compatible instruction set
Resolution	203DPI, 8 dots/mm
Paper Width	57 mm±0.5mm
Effective Printing Width	48 mm(384dots)
Paper Roll Diameter	30mm(max)
Appearance of size	82mmx58mmx57mm(LxWxH)
Opening size	77mmx53mm(LxW)
The barcode	UPC-A; UPC-E; EAN-8; EAN13; CODE39; ITF; CODEBAR; CODE128; CODE93; QR CODE; PDF417
The code page	Supports 45 international character sets, including simplified Chinese, traditional Chinese, English, and Japanese characters
The chart	Support different density of point map, grating bitmap and download bitmap printing
Tearing way	Manually tearing
Print head span	50km
The power supply	5-9V/12V
