Instruction set

ESC/POS compatible instruction set

Resolution

203DPI, 8 dots/mm

Paper Width

57 mm±0.5mm   , 54 mm±0.5mm   , 44 mm±0.5mm   , 34 mm±0.5mm   , 24 mm±0.5mm

Effective Printing Width

48 mm(384dots)

Paper Roll Diameter

60mm(max)

Appearance of size

111mmx89mmx73.5mm(LxWxH)

Opening size

106.3mmx84mm(LxW)

The barcode

UPC-A; UPC-E; EAN-8; EAN13; CODE39; ITF; CODEBAR; CODE128; CODE93; QR CODE; PDF417

The code page

Supports 45 international character sets, including simplified Chinese, traditional Chinese, English, and Japanese characters

The chart

Support different density of point map, grating bitmap and download bitmap printing

Tearing way

Manually tearing

Print head span

50km

The power supply

5-9V/12V
