2 inch/3 inch Thermal Label Printer


    •  Fashionable design
  • •  448/640 dots supported
  • •  Max. 80mm effective printing width
  • •  With optional Bluetooth 4.0 module
  • •  Built-in power adapter
  • •  30% smaller, space-saving
  • •  Support larger diameter paper roll and external paper inlet

    EMAIL   INQUIRY

ModelD21D31
PrintingPrint MethodDirect Thermal
Resolution203 dpi (8 dots/mm)
Print SpeedMax. 60 mm/sMax. 80 mm/s
Length15 mm ~ 300 mm
InterfaceStandardUSB Type B
OptionBluetooth 4.0(Factory installed)
Programming LanguageTSPL
MemoryRAM2 MB
ROM2 MB
MediaType
Roll or Fanfold label, die cut or continuous direct thermal labels, Tag stock, Continuous Receipt Paper
Diameter(Media Roll)90 mm
Thickness0.003"(60μm) ~ 0.007"(180μm)
BarcodeLinear BarcodesCODE39,  CODE93, EAN-8, EAN-13, EAN-2, EAN-5, UPC-A, UPC-E
2D BarcodesQR code
SensorsGap SensorTransmissive(Fixed)
Other
Paper Out Sensor, Head-Up Sensor, TPH temperature detection
Power AdapterInputAC 100V ~ 240V, 50/60Hz
OutputDC 12V, 2A
Physical Characteristics182.5×134×120.6 mm210×154×135 mm
Empty weight
0.805kg0.88kg
Options & AccessoriesBluetooth 4.0, External Label Roll Holder
ReliabilityTPH 50 km
SoftwareDriverWindows Vista/7/8/10
Windows Server 2008/Server
2012/Server 2016
Agency Approvals
CCC, FCC, CE
